M9484F1007/U Compact Servo Motor for Control Systems
Compact Servo Motor for Control Systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Modutrol IV Proportional Motor Actuator |
| Voltage | 24 VAC |
| Control Signal | 135 ohm proportional input |
| Stroke | Field‑adjustable 90 to 160 degrees |
| Stroke Running Time | 30 to 60 seconds |
| Torque | 150 lb‑in |
| Auxiliary Switches | 2 auxiliary switches |
| Power Loss Action | Non‑spring return |
| NEMA Rating | NEMA 3 |
| Ambient Temperature Range | -40 to 150 degrees Fahrenheit |
| Shaft Type | Double‑ended square shaft |
| Weight | Approx 8 lbs |
Notes
Product Overview
The M9484F1007/U is a compact proportional motor actuator from the Honeywell Modutrol IV series, designed for precise control of valves and dampers in industrial and commercial automation systems. It operates on a standard 24 VAC power supply with a 135 ohm proportional control signal for reliable modulation of mechanical linkages.
Equipped with dual auxiliary switches, this actuator provides enhanced feedback capability for control systems requiring position indication or integrated switch control. Its adjustable stroke range and robust construction make it suitable for control systems in HVAC, burners, and other industrial automation applications.
Key Features
- Compact Modutrol IV proportional motor for control systems
- 24 VAC operation with 135 ohm proportional input
- Adjustable stroke from 90 to 160 degrees
- Dual auxiliary switches for feedback and control signal options
- Stroke timing from 30 to 60 seconds
- 150 lb‑in torque for efficient actuation
- Non‑spring return for modulating control
- NEMA 3 housing for durability
- Double‑ended shaft for flexible linkage connection
- Suitable for HVAC, burner, and industrial control
Packaging & Delivery
- Protective industrial carton packaging
- Export packing for international shipments
- Fast processing for stocked units
- Courier, air, or sea shipping options
- Bulk order support for distributors
Frequently Asked Questions (FAQ)
Q: What is the M9484F1007/U used for?
A: It is used to control valves and dampers in industrial automation and control systems.
Q: How many auxiliary switches are included?
A: This model includes two auxiliary switches.
Q: What power supply does this actuator require?
A: It operates with a 24 VAC power supply.
Q: Can this servo motor be used in burner control systems?
A: Yes, it is suitable for burner firing rate valve control and related automation.
Q: Does this actuator support modulating control?
A: Yes, it uses a proportional input signal for smooth modulating actuation.
