C6097 Series
Gas & Air Pressure Switches
Reliable safety monitoring for industrial combustion systems. Ensure precise pressure verification before ignition and during operation.
Series Overview
The C6097 Series is a family of industrial gas and air pressure switches designed for safety monitoring and control in combustion and burner systems. These pressure switches are commonly used to verify gas or air pressure conditions before burner ignition and during operation, ensuring safe shutdown in abnormal pressure scenarios.
The series is widely applied in industrial burner systems where precise pressure supervision is required to protect combustion equipment and meet safety standards.
Functional Role in Burner Systems
Within an industrial burner control system, C6097 Series pressure switches are used to:
- Confirm minimum or differential gas/air pressure before ignition
- Detect pressure loss during burner operation
- Trigger safety shutdown to prevent unsafe combustion
- Provide interlock signals to burner controllers
These switches operate as critical safety components rather than process control instruments.
Key Differences
Key Differences Within the C6097 Series
Although all C6097 models share the same core safety function, different variants are designed to support specific system requirements. Primary differentiation factors include:
- Pressure sensing type (gas, air, or differential pressure)
- Pressure adjustment range and sensitivity
- Manual reset or automatic reset behavior
- Application focus (burner safety, boiler systems, HVAC integration)
Typical Applications
- Industrial gas burner safety systems
- Boiler and combustion control panels
- HVAC and industrial heating equipment
- Gas and air pressure monitoring circuits
- Pre-purge and interlock safety chains
Model Comparison
| Model | Pressure Type | Key Feature | Typical Application |
|---|---|---|---|
| C6097A3004/U | Gas / Air | Standard safety switch | Industrial burner systems |
| C6097A3012/U | Gas (Low Pressure) | Low-pressure detection | Combustion safety control |
| C6097A3038/U | Differential | Gas/Air monitoring | Pressure balance supervision |
| C6097A3053/U | Gas | Industrial-rated | Burner safety circuits |
| C6097A3095/U | Gas | Adjustable setpoint | Flexible safety control |
| C6097A4110/U | Gas | HVAC compatible | Gas detection & safety |
| C6097A4110B/U | Gas | Manual reset | Enhanced safety requirement |
| C6097A4210/U | Differential (Low) | High sensitivity | Safety shutdown systems |
| C6097A4210B/U | Gas | Boiler focused | Combustion equipment |
| C6097A4210D/U | Gas | Precision monitoring | Stable pressure detection |
| C6097A4310/U | Air / Gas | Industrial design | Burner control integration |
| C6097A4310B/U | Gas | Enhanced reliability | Safety control panels |
| C6097A4410/U | Gas | Wide adjustment range | Multi-condition systems |
| C6097A4410B/U | Gas | High precision | Critical safety monitoring |
| C6097B3028/U | Gas (Rising) | Rising pressure detection | Combustion safety logic |
Selection Guide
Standard Safety
Choose standard C6097A models for conventional burner safety interlocks.
High Precision
Select low or differential pressure models for precise air/gas balance monitoring.
Manual Reset
Use manual reset versions where operator confirmation is required after shutdown.
Wide Range
Recommended for systems with fluctuating pressure conditions or strict tolerances.
